Automatic Die Cutting Creasing Machine With Auto Stripping Model AEM-1080Q

Quantity:
  • AEM-1080Q
  • Koten
  • AEM-1080Q
  • Negotiable
  • One set
  • T/T,L/C
  • 30sets/month
  • By strong seaworthy wooden cases
  • Within 30 days after get the depoait.
  • China
  • 1161

Features

★ Automatic pressure adjust system, pressure digital display.

★ Human-friendly designed die frame and baseplate, makes installation, adjustment convenient.

★ Pneumatic die locking device, die frame fixed more steadily, accurately, time saving.

★ Front lay, side lay, feeding device fine tuning device, paper positioning more accurate,

★ Double, crooked, empty optoelectronic position control, ensure the paper in the right position, reduce waste.

★ Electronic control module design, adopt imported electronic components, ensure the accuracy and reliability.

★ Touch screen man-machine interface, real-time monitor the running situation, makes machine adjustment, trouble shooting more convenient.

★ Cycling cooling oil supply system ensure the movement parts get adequately lubricated to ensure the durability.

★ Adopt fixed quantity at fixed timing oil supply system, ensure the movement parts get adequately lubricated to let better durability.

Die cutting plate.

20140427_210745_副本

Main technical parameters

Model                                         800Q                          1080Q

Max paper size:                        800 x 620 mm          1080x780mm

Min paper size:                        340 x280 mm           450x400mm

Max cutting size:                      770 x 600 mm           1075x770mm

Die frame inner size:                  820 x 628 mm           1100x800mm

Cutting plate size:                     826 x 628 mm           1100x800mm

Min gripper edge size:                 7 mm                    7mm

Cutting precision:                     ≤±0.1 mm                 ≤±0.15mm

Max cutting pressure:                 200 T                     300T

Max cutting speed:                    7000 S/H                   7000 S/H

Pre-stacking height:                   1150 mm                   1150 mm

Delivery stack height:                 1000 mm                    1100 mm

Application:

        White board:                0.1~2 mm                  0.12~2 mm

        Corrugated paper:            <4 mm                     <4 mm

Main motor power:                  7.5 KW                       11KW

Total power:                        12.75 KW                     17.8KW

Dimension :          【L(+ pre-stacking)x W(+ platform)x H】

AEM-800Q:     5150(+1360) x 2000(+1300) x 1690 mm

AEM-1080Q     6800x3780x2050mm

AEM-800Q weight:    9.5 T

AEM-1080Q weight    14T


Koten Machines Container Loading.

光影魔术手拼图
140 Countries Clients Who Has Koten Brand Machines Till 2019.

1

FAQ.

1. Why choose us to cooperate?
Factory prices, flexible payment terms and professional quality inspection team which has the guarantee for machines, in time after sales service, and more than 15 years experience for exporting. Reputation and quality is what we are considering all the time.


2. Guarantee.

There is 12 month guarantee of each Koten brand Machines since customer got the machine. Within one year, the damaged spare parts can be changed for free, and we provide lifetime technology support on line.


3. Delivery Time.

Within 7-30 days after get the deposit. Depends on different machines.


4. What is your package?

What the package we use is strong seaworthy wooden cases. Each machine will be protected by anti-rusted oil before put into the case and there are desiccants will be packed into the machine together.


5. Do you have Installation and Training service if we bought the machines from your company?

The training service will be done by our agency dealer in some countries. If customers request us to dispatch our engineer to their country for installation and training, customers should take all necessary cost, like return flight tickets, hotel, food and salary USD100/day. If customer dispatch their engineer to our factory for training, it is free.


6. Have you sold any machines to our country?

We have to say that there are 140 countries' customers who have the "KOTEN" brand machines till 2019. Pls check with the sales manager to get more information if you need the machines' feedback.


7. What is your payment terms?

T/T. If the amount less than USD30,000.00, 30% paid in advance as a deposit, 70% balance paid before shipment.
L/C. If the sales amount above USD30,000.00, 30% paid by T/T as a deposit, 70% balance paid by irrevocable L/C at sight.
By Cash, by western union, credit cards are acceptable.
Special country like Bangladesh or Algeria can be available for 100% by irrevocable L/C at sight.


8. What your company can offer?

Exercise Books Making Solutions.
Soft Cover Books Making Solutions.
Hard Cover Books Making Solutions.
Spiral Books Making Solutions.
Postpress and Paper Converting Solutions.
Paper Box Making Solutions.
Rigid Box Making Solutions.

Paper Bag Making Solutions.


Exhibitions and Customers'Meeting.
光影魔术手拼图

     Factory Production.
1-2
