DFJ-1300/1400/1600
Koten
DFJ-1100/1400/1600
Negotiate
1set
T/T
50sets/month
By strong seaworthy wooden cases.
Within 30 days after get the deposit.
China
238
Availability: | |
---|---|
Quantity: | |
Main features:
This machine is suitable for cutting the large coil packaging material, such as the paper, paper plastic complex material and color printing complex material, etc. This machine is widely used for application in the industries of paper processing and printing packaging.
Application range:
The machine is suitable for cutting in longitudinal direction and cross direction the colied materials like paper, trademarks, cigarette labels, wall calendars, spirits boxes, playing cards, paper-plastic compound materials, etc.
Function: Transverse cutting with flat blade, automatic feeding, automatic stowing and photoelectric tracking.
Main Specifications.
Model | DFJ-1100 | DFJ-1400 | DFJ-1600 | DFJ-1700 |
Max.Raw Material Diamenter | 1400mm | 1400mm | 1400mm | 1400mm |
Max.Cutting Width | 1100mm | 1400mm | 1600mm | 1700mm |
Cutting Length | 20-1200mm | 20-1200mm | 20-1200mm | 20-1200mm |
Precision | 0.2mm | 0.2mm | 0.2mm | 0.2mm |
Speed | 80-100m/min | 80-100m/min | 80-100m/min | 80-100m/min |
Max.Pile Height | 1200mm | 1200mm | 1200mm | 1200mm |
Total Power | 8kw | 9kw | 10kw | 11kw |
Voltage | 3P 380V 50HZ | |||
Air Pressure | Max.5.5kgs/cm2x5m3/min | |||
Weight | 3200kgs | 3800kgs | 4300kgs | 4500kgs |
Dimension | 7x1.7x1.8m | 7x2.2x1.9m | 7x2.4x1.9m | 7x2.5x1.9m |
Koten Machines Container Loading.
140 Countries Clients Who Has Koten Brand Machines Till 2019.
2. Guarantee.
3. Delivery Time.
4. What is your package?
5. Do you have Installation and Training service if we bought the machines from your company?
6. Have you sold any machines to our country?
7. What is your payment terms?
8. What your company can offer?
Paper Bag Making Solutions.
Exhibitions and Customers'Meeting.
Factory Production.
Main features:
This machine is suitable for cutting the large coil packaging material, such as the paper, paper plastic complex material and color printing complex material, etc. This machine is widely used for application in the industries of paper processing and printing packaging.
Application range:
The machine is suitable for cutting in longitudinal direction and cross direction the colied materials like paper, trademarks, cigarette labels, wall calendars, spirits boxes, playing cards, paper-plastic compound materials, etc.
Function: Transverse cutting with flat blade, automatic feeding, automatic stowing and photoelectric tracking.
Main Specifications.
Model | DFJ-1100 | DFJ-1400 | DFJ-1600 | DFJ-1700 |
Max.Raw Material Diamenter | 1400mm | 1400mm | 1400mm | 1400mm |
Max.Cutting Width | 1100mm | 1400mm | 1600mm | 1700mm |
Cutting Length | 20-1200mm | 20-1200mm | 20-1200mm | 20-1200mm |
Precision | 0.2mm | 0.2mm | 0.2mm | 0.2mm |
Speed | 80-100m/min | 80-100m/min | 80-100m/min | 80-100m/min |
Max.Pile Height | 1200mm | 1200mm | 1200mm | 1200mm |
Total Power | 8kw | 9kw | 10kw | 11kw |
Voltage | 3P 380V 50HZ | |||
Air Pressure | Max.5.5kgs/cm2x5m3/min | |||
Weight | 3200kgs | 3800kgs | 4300kgs | 4500kgs |
Dimension | 7x1.7x1.8m | 7x2.2x1.9m | 7x2.4x1.9m | 7x2.5x1.9m |
Koten Machines Container Loading.
140 Countries Clients Who Has Koten Brand Machines Till 2019.
2. Guarantee.
3. Delivery Time.
4. What is your package?
5. Do you have Installation and Training service if we bought the machines from your company?
6. Have you sold any machines to our country?
7. What is your payment terms?
8. What your company can offer?
Paper Bag Making Solutions.
Exhibitions and Customers'Meeting.
Factory Production.
