DC37D
Koten
DC37D
Negotiate
One set
T/T, L/C At Sight
30 sets/month
By strong sea worthy wooden cases.
Within 30 days after receipt of the deposit.
China
2698
| Quantity: | |
|---|---|
This equipment is the latest research and development product ,Equipped with diecutting, intermittent die-cutting and slitting units, it adopt advanced servo control system, user- friendly operation panel, greatly improve product quality and production efficiency; with the latest full-rotary and intermittent interchangeable technology; suitable for digital printing label small and medium quantity orders after die-cutting.
Model | 370 | 480 |
Max. Web Width | 370 mm | 480 mm |
Die Cutting Repeat | 50-444.5 mm | 50-444.5 mm |
Die Cutting Precision | ±0.15 mm | ±0.15 mm |
Max. Unwinding Dia | 800 mm | 800 mm |
Max. Up Rewinding Dia | 450 mm | 450 mm |
Max. Down Rewinding Dia | 800 mm | 800 mm |
Rewind Inner Core Size | 1 ~6 inch (standard in 3 inch) | 1 ~6 inch (standard in 3 inch) |
Thickness Of Material | 20-300 um | 20-300 um |
Air Source | 0.8 Mpa | 0.8 Mpa |
This equipment is the latest research and development product ,Equipped with diecutting, intermittent die-cutting and slitting units, it adopt advanced servo control system, user- friendly operation panel, greatly improve product quality and production efficiency; with the latest full-rotary and intermittent interchangeable technology; suitable for digital printing label small and medium quantity orders after die-cutting.
Model | 370 | 480 |
Max. Web Width | 370 mm | 480 mm |
Die Cutting Repeat | 50-444.5 mm | 50-444.5 mm |
Die Cutting Precision | ±0.15 mm | ±0.15 mm |
Max. Unwinding Dia | 800 mm | 800 mm |
Max. Up Rewinding Dia | 450 mm | 450 mm |
Max. Down Rewinding Dia | 800 mm | 800 mm |
Rewind Inner Core Size | 1 ~6 inch (standard in 3 inch) | 1 ~6 inch (standard in 3 inch) |
Thickness Of Material | 20-300 um | 20-300 um |
Air Source | 0.8 Mpa | 0.8 Mpa |
