JP-1/2/3
Koten
JP-1/2/3
Negotiate
One set
TT,LC
30 Sets/month
By Strong Seaworthy Wooden Cases.
Within 10-30 days after get the deposit.
Wenzhou
4379
| Quantity: | |
|---|---|
●The precise alignment of the cutting reams improves the quality considerably.
●Enables quality control.
●Increases the efficiency of the cutting machine cutting machine and unloader.by up to 40% because cutting can be continued while new material is prepared.
●Blocks can be formed more easily from the layers owing to mechanized removal of air.
●Four automatic table inclination angles on the right/left side just need one touch.
Model | JP-1 | JP-2 | JP-3 |
Max sheet size | 870x720mm | 1150x900mm | 1450x1130mm |
Max ream height | 165mm | 165mm | 165mm |
Worktable height | 880-980mm | 880-980mm | 880-980mm |
External dimension | 1270x1170x1875mm | 1550x1290x1875mm | 1850x1570x1875mm |
| As a result of technology improvement,the technical parameters is subject to change without notice | |||
Parts | Brand | Origin |
Approach switch | Panasonic | Japan |
Limit switch | Panasonic | Japan |
Frequency converter | Delta | Taiwan |
Contactor (switch) | Schneider | France |
Relay | Schneider | France |
PLC | Delta | Taiwan |
Ball screw | TBI | Taiwan |
Bear | NSK | Japan |
●The precise alignment of the cutting reams improves the quality considerably.
●Enables quality control.
●Increases the efficiency of the cutting machine cutting machine and unloader.by up to 40% because cutting can be continued while new material is prepared.
●Blocks can be formed more easily from the layers owing to mechanized removal of air.
●Four automatic table inclination angles on the right/left side just need one touch.
Model | JP-1 | JP-2 | JP-3 |
Max sheet size | 870x720mm | 1150x900mm | 1450x1130mm |
Max ream height | 165mm | 165mm | 165mm |
Worktable height | 880-980mm | 880-980mm | 880-980mm |
External dimension | 1270x1170x1875mm | 1550x1290x1875mm | 1850x1570x1875mm |
| As a result of technology improvement,the technical parameters is subject to change without notice | |||
